VGA Fan Spec
| part no. | part name | bearing | speed rpm | rated Volt | current A | watt W | airflow CFM | pressure mm-aqua | noise dBA |
|---|---|---|---|---|---|---|---|---|---|
| F124008S08P | VGABallA | 1S | 8000 | 12 | 0.25 | 3.0 | (2.0) | (15) | 34 |
| F124008S06P | VGABallB | 1S | 6000 | 12 | 0.15 | 1.8 | (1.6) | (10) | 30 |
| part no. | part name | bearing | speed rpm | rated Volt | current A | watt W | airflow CFM | pressure mm-aqua | noise dBA |
|---|---|---|---|---|---|---|---|---|---|
| F124008S08P | VGABallA | 1S | 8000 | 12 | 0.25 | 3.0 | (2.0) | (15) | 34 |
| F124008S06P | VGABallB | 1S | 6000 | 12 | 0.15 | 1.8 | (1.6) | (10) | 30 |
